Cat 953K track loader improvements announced


Caterpillar has announced that its new Cat 953K track loader will build on the solid design of its predecessor by increasing fuel efficiency, providing greater control, delivering smoother shifts, and enhancing operator safety and comfort.

The 953K is powered by a 132kW Cat C7.1 Acert engine that meets EU Stage IV emission standards. An Eco Mode automatically reduces engine speed, but maintains selected ground speed when the machine is under light load. The more efficient engine and the Eco Mode combine to deliver up to 22% better fuel economy compared with the 953D.

An optional high-capacity Performance Series bucket moves up to 10% more material per hour. For added versatility, an optional Fusion Quick Coupler (available mid-2017) will allow easy use of work tools such as buckets and forks from wheel loaders and other Fusion compatible machines. Purpose-built Waste and Ship Hold arrangements equip the machine for optimal performance in special applications. Also, efficient use of diesel exhaust fluid (DEF) – typically 2.5-3% of fuel consumption – provides excellent overall fluid efficiency.

The Caterpillar telematics system, Product Link, is deeply integrated into the 953K, and provides timely access to information such as machine location, hours, fuel usage, idle time, and event codes via the online VisionLink user interface.

A new powertrain management system ensures smoother implement and steering performance, and power is delivered to the ground more efficiently, for fast acceleration and shorter cycle times. Load-sensing hydraulics and position-sensing cylinders add to the machine’s precision and response.

Selectable electrohydraulic mapping allows adjusting implement response to fine, normal, or coarse settings to match operator preferences and to tailor the machine to individual applications. In addition, the wide selection of transmission gear ranges, six forward and six reverse, allow further adjusting the machine to the application.

The updated cab provides operator-comfort refinement, such as a suspension seat, adjustable armrests and controls, and a more efficient air conditioning system.

Engine noise is reduced compared to the 953D, resulting in a quieter environment both for the operator and for bystanders. Safety is enhanced as well, with added handles and steps that assist with safer cab ingress/egress, from either the front or the back of the tracks.

Cat emissions reduction technology is designed to be transparent – with no action required from the operator and no need to stop for regeneration. The DEF fill point is located at ground level, next to the fuel tank, for convenient access when refueling.

The 953K maintains its reputation for ease of service too, with a tilt cab and convenient service access points. In addition, the demand fan provides efficient cooling, and features a swing-out grill door and fold-down fan to help make cleanout quick and easy.
